Circuitree Pro

Android App Analysis and Review: Circuitree Pro, Developed by Mantex Studios. Listed in Tools Category. Current Version Is 2.1.0, Updated On 10/03/2025 . According to users reviews on Google Play: Circuitree Pro. Achieved Over 960 Installs. Circuitree Pro Currently Has 25 Reviews, Average Rating 4.4 Stars

Circuitree allows you to explore the huge and fascinating electronics world, with an always growing circuit catalogue.

- LEARN
For each circuit you can consult formulas and information that help you understand how it works.

- SIMULATE
Insert the values of the components of the circuit and let the app compute all the values in real time, also with time graphs and bode plots.

- DESIGN
Let the app compute the values of the components you need in order to obtain your desired result from the circuit. The tool also includes the possibilities to use and compute only standard value resistors, to have your circuit ready for practical implementation.

Here you can find, more in detail, the main simulation features of Circuitree:
- voltages and currents
- power dissipation
- time diagrams
- Bode plots
- estimate the duration of a battery powering the circuit

And here, the main design features:
- perform inverse calculation to find the value of the component
- standard value series for resistors and capacitors
- auto-design tool

Auto-design tool:
This tool allows you to find all the combinations of standard values that result in the value you want. This makes much more easier to choose components' values in order to get, for example, a certain gain or frequency , also based on the physical components you have.

Save circuits:
Once you've sized all the values and got the circuit to behave as you want, you can save the circuit configuration, in order to visualize and modify it any time you want. (Pro version feature)

Circuitree is always growing also thanks to your help: if you have any circuit to suggest, go to the specific section and send your suggestion!

Whether you are a student, an enthusiast or a professionist, if you deal with electronics, Circuitree is the app for you!
